Locate the idle set screw at the very bottom of the Tillotson carburetor. … Find the low-speed adjustment screw with the “L” next to it on the carburetor body. … Locate the high-speed adjustment screw with the “H” on the body. … Start the motor and let it warm up for a few minutes.

How do I get my Tillotson Carb to idle?

Open the throttle about one quarter of full travel and firmly pull the starting cord until the engine fires. Open the choke shutter far enough to allow the engine to idle until it has warmed up enough to run continuously with the choke fully open.

How do you adjust the float on a Tillotson carburetor?

To adjust the float level, remove the cover to which the needle valve and float assembly are attached. Hold the assembly in an inverted position and bend the float lever arm until the correct setting is obtained. Two points should be considered when checking float level on Tillotson carburetors.

Where are the adjustment screws on a carburetor?

Find the adjustment screws on the front of the carburetor. There should be two screws on the front of the carburetor, which are used to adjust the air and fuel mixture. Often these look like flat-head screws and you can use a screwdriver to turn them, adjusting the amount of fuel and air mixing in the carb.

How do you adjust a Tillotson HS carburetor?

1. Locate the idle set screw at the very bottom of the Tillotson carburetor. …
2. Find the low-speed adjustment screw with the “L” next to it on the carburetor body. …
3. Locate the high-speed adjustment screw with the “H” on the body. …
4. Start the motor and let it warm up for a few minutes.

What does the float needle do in a carburetor?

The carburetor float needle, moved by the float, controls fuel flow, maintaining the fuel level in the chamber. As suggested by its name, the “float” needs to float in the fuel, so it’s usually made of hollow plastic, metal or fuel-resistant foam — some were made of cork in the old days.

How do you adjust a carburetor mixture?

Run the engine for five minutes at half throttle to bring it to its operating temperature. Then, turn the idle mixture screw slowly clockwise until the engine begins to slow. Turn the screw in the opposite direction until the engine again begins to slow. Finally, turn the screw back to the midpoint.

How do you tell if a carburetor is rich or lean?

This method involves looking at the base of the spark plug insulator (white part of the plug) for a slight coloring on the insulator just above where the insulator comes through the steel case. If the mixture is too lean, it will leave no color, while a rich mixture will cause the fuel ring to become more prominent.

How do I set my carburetor to use less fuel?

Once the engine has arrived at operating temperature, go back to the carburetor and adjust the air fuel mixture screw, or screws. Tightening the screw increases the amount of fuel, while loosening decreases the amount of fuel.

What does it mean when a carburetor is running rich?

When a vehicle is running rich, the fuel-to-air ratio is off because the carburetor is delivering too much gasoline. Typical symptoms of a rich mixture are: Poor fuel economy. … Strong smell of gasoline when the machine is at idle.

Article first time published on

What is the proper air fuel ratio?

The stoichiometric mixture for a gasoline engine is the ideal ratio of air to fuel that burns all fuel with no excess air. For gasoline fuel, the stoichiometric air–fuel mixture is about 14.7:1 i.e. for every one gram of fuel, 14.7 grams of air are required.

Which way do you turn a mixture screw?

On most carburetors, turning the mixture screw in (clockwise) leans the mixture, while counterclockwise (out) enriches the mixture. Initially, if the engine stumbles or the vacuum drops when turning the mixture screw in, turn both screws out about a -turn and evaluate the results.

How do you fix rich air/fuel mixture?

1. Check The Air Duct’s Flap. The flap inside the air duct is an actuator that serves as choke.
2. Vacuum Lines And Hoses. …
3. Clean The Mass Airflow Sensor. …
4. The Oxygen Sensor. …
5. Change the spark plugs.

Is it better to run lean or rich?

TLDR – running just a little lean could improve fuel economy and give extra power. However, run too lean and you risk engine failure because the engine runs too hot. Whereas running rich can waste fuel and increase pollution but will not damage the engine.

Is clockwise lean or rich?

* Here, if you turn the screw towards the engine (CLOCKWISE) the carb sends in more fuel. This is also referred to as “running rich”. Whereas, if you turn the screw towards the air filter (COUNTERCLOCKWISE), the carb sends in more air. This is referred to as “running lean”.

How do I know if my carburetor float is stuck?

One of the signs that the carburetor float is sticking is when the engine will not idle. The float is not letting enough fuel into the reservoir, allowing for a constant idle of the engine. The carburetor float is stuck in the closed position, and only a small amount of fuel is seeping into the reservoir.

What is the position of float needle valve?

A true needle valve uses a tapered needle in a tapered seat, so as to provide fine control over flow rate. The float valve uses a pointed needle against a square-edged seat, to give a positive shut-off. As the float relies on gravity, the chamber must be mounted vertically.
